Led Indication - Refco Vamp-F Kurzanleitung

Alarm Relay Operation Table
Pump Status
Not powered
Powered
Powered

LED Indication

Status
No Power
Startup LED
Idle
Pumping Water
High water level
Alarm mode relay
High temperature
Invalid state
Condensate Level
N/A
Below alarm level
Alarm activated
LED Pattern
Default Operation
NC
NC
NC
red green
Reason
Miswired, unplugged
or no voltage
Pump is starting
No water to pump
Pump is running
Increased pump
speed
High water level,
alarm activated
High temperature
detected
Sensor needs cleaning
COM
COM
COM
