3 speed stages: see also Fig. 2c
c1, c2, c3
The pump is set at a fixed speed within the 3 speed stages
control mode.
NOTICE: If a standard heating pump is replaced with this
high-efficiency pump, the button can be set on the first, sec-
ond, or third characteristic curve (c1, c2, c3) on the 3 speed
stages scale as a reference point for adjusting the pump
setpoint.
Setting the delivery head / speed stage
The setpoints / speed stages can be increased or
decreased by turning the button to the left or right within the
selected control mode. In the Δp-v or Δp-c control mode,
the setting can be carried out in 0.1 m steps.
When the button is turned in the Δp-v or Δp-c control mode,
the display changes to the set pump setpoint. The "m" sym-
bol will light up.
In the 3 speed stages mode, c1, c2, or c3 is shown for the
relevant pump characteristic curve.
If the button has not been turned for a duration of 2 seconds,
the display will change back to the current power consumption
after flashing 5 times. The "W" symbol will light up.
NOTICE: All settings and displays are retained if the mains
supply is interrupted.
26
