Commend Front panel EF 031x Montageanleitung

Front panel EF 031x
Dimensions / Connection
Measuring units in mm (in), not to scale!
Ribbon cable
to EB 330 or
ECB 030
Safety instructions
• This device shall be installed or replaced by trained and qualified personnel only.
• The device may only be cleaned with cleaning agents for stainless steel. Do not use cleaning agents
containing chlorine or isopropanol.
Handling
Use the original packaging when transporting the device to prevent damage.
Observe the precautions for handling of electrostatic sensitive devices.
Disposal and recycling
Equipment with this symbol shall not be disposed of together with household or commercial
waste.
The directive 2012/19/EU on waste electrical and electronical equipment (WEEE) is applicable
in the European Union member states.
Manufacturer's reference
This device complies with the European directives listed below by fulfilling corresponding
standards:
• Electromagnetic compatibility (directive 2014/30/EU)
• The restriction of the use of certain hazardous substances in electrical and electronic
equipment (directive 2011/65/EU)
For technical specifications, see the respective datasheet.
For the latest software and documentation, visit: www.commend.com
Keep this description in safe custody.
Type: D-BZ-EF031, Version: 2.5/0623 Commend International GmbH, Saalachstraße 51, A-5020 Salzburg – www.commend.com
179 (7.05)
LED
Attention: The number
of buttons and other
options depend on the
type of station ordered.
