Sentiotec BASIC-M Montageanleitung Seite 6

Instructions for installation and use
1.5. Basic Corner parts list
No. of
Name
items
Wall elements
1 Lower rear wall element
1 Lower left side wall element
1 Lower right side wall element
1 Upper rear wall elements
1 Upper left side wall element
1 Upper right side wall element
2 Wall element
2 Wall element
1 Log board with ventilation gap
1 Log board
Roof elements
2 Roof elements
Support slats
2 Roof support slats
2 Roof support slats
4 Cover slats
4 Door cover slats
4 Door cover slats
1 Roof cover slat
1 Cable cover slat
2 Bench support slats
2 Bench support slat
p. 6/14
Dimensions
185 x 82,6 x 4 cm
154,5 x 82,6 x 4 cm
154,5 x 82,6 x 4 cm
185 x 96,2 x 4 cm
154,5 x 96,2 x 4 cm
154,5 x 96,2 x 4 cm
82,6 x 55,6 x 4 cm
96,2 x 55,6 x 4 cm
185 x 4 x 14,6 cm
185 x 4 x 13,6 cm
145,5 x 92 x 5.7 cm
180 x 4 x 4 cm
150 x 4 x 4 cm
204 x 8 x 1.5 cm
68 x 8 x 1.5 cm
188,9 x 8 x 1.5 cm
145,5 x 8 x 1,5 cm
150 x 4 x 3 cm
50 x 4 x 4 cm
100 x 4 x 4 cm
