Part number
Type approval
Rated voltage
Operating voltage
Total current
17
consumption
Light function
Interference suppression
class CISPR 25
Power consumption
Dome
Operating position
Protective rating
Temperature range
Inverse polarity
protection
Housing
Technical Data
013 878-001
013 878-011
SAE - J845 Class 1
ECE - R65 TA1
ECE - R10
12 V / 24 V
9-32 V
Rotating ≤0,60 A / (9-32 V)
Flashing ≤2,22 A / (9-32 V)
Flashing and rotating
CISPR 25 Class 3
ca. 9-30 W
PC
Upright
IPX 9K, IP 67
-40 ºC
+60 ºC
yes
PC + ABS black
Program mode description
No.
Flash patterns
1
Double flash (default mode)
2
Rotating
• The lamp must be put in operation (white to positive
terminal (plus +), black to negative terminal (minus -)).
• The predefined pattern is Double flash, so at the first
connection the lamp will light up in this flashing mode.
• To change from Double flash to Rotating pattern:
Connect or touch the "flashing/rotating selection" yel-
low wire to the black wire (minus -) for at least 3
seconds while the current pattern continues.
After approximately 3 seconds, the LEDs will turn off,
indicating a pattern change.
Once the LEDs have turned off, disconnect the two wires,
and the new pattern will remain active.
Remark: For the pipe socket version, changing the
pattern is possible by removing the pipe socket adapter.
The desired flash pattern must be preset before
mounting the product to the vehicle.
Calculate the fuse according to the capacity of the
consumer and the cable cross-section required for this!
2Hz
2Hz
