Hold power tool by insulated gripping surfaces when performing an operation where the
cutting tool may contact hidden wiring or its own cord.
▪
When ripping always use a rip fence or straight edge guide.
▪
Always use blades with correct size and shape (diamond versus round) of arbor holes.
▪
Never use damaged or incorrect blade washers or bolt.
6.1
Guard function
▪
Check guard for proper closing before each use. Do not operate the saw if guard does not
move freely and enclose the blade instantly. Never clamp or tie the guard so that the blade
is exposed. If saw is accidentally dropped, guard may be bent. Check to make sure that
guard moves freely and does not touch the blade or any other part, in all angles and
depths of cut.
▪
Check the operation and condition of the guard return spring. If the guard and the spring
are not operating properly, they must be serviced before use. Guard may operate
sluggishly due to damaged parts, gummy deposits, or a build-up of debris.
▪
Assure that the base plate of the saw will not shift while performing the "plunge cut" when
the blade bevel setting is not at 90°. Blade shifting sideways will cause binding and likely
kick back.
▪
Always observe that the guard is covering the blade before placing saw down on bench or
floor. An unprotected, coasting blade will cause the saw to walk backwards, cutting
whatever is in its path. Be aware of the time it takes for the blade to stop after the switch is
released.
7 ASSEMBLY
7.1
Replacing the saw blade (Fig. 1)
Only use sharp and undamaged saw blades. Cracked or bent saw blades must be replaced
immediately.
▪
Place the circular saw on its side on a flat surface
▪
Rotate the saw blade by hand while depressing the spindle locking button until the blade
locked. Turn the blade clap bolt anti-clockwise by using the hex key.
▪
Remove the flange.
▪
Raise the guard by using the lever guard and then remove the saw blade.
▪
Remove the old saw blade and place the new saw blade (9) with the teeth pointing in the
direction of rotation. See the arrow on the housing.
▪
Move the saw blade guard back into its normal position.
▪
Place the flange on the saw blade and secure the fixing screw.
Before replacing the saw blade always unplug the tool.
▪
Never use saw blades with a thickness exceeding the thickness of the riving knife or saw
blades with a tooth setting smaller than the thickness of the riving knife.
▪
Do not use saw blades made of HSS steel. Make sure that the spindle diameter
corresponds to the bore diameter.
7.2
Adjusting the depth of cut (Fig. 2)
▪
Loosen the lock lever for depth adjustment
▪
Hold the base plate flat against the edge of the work piece and lift the body of the saw until
the blade is at the right depth determined by the depth gauge.
▪
Tighten the lock lever for depth adjustment
7.3
Setting the mitre angle (Fig. 3)
▪
The mitre angle is infinitely variable between 0° and 45°.
▪
Loosen the set screws (4).
▪
Set the required mitre angle using the scale (10).
