Hama 2in1 Zapper Bedienungsanleitung Seite 5

5.2.1 Switch the device you wish to operate on.
5.2.2 Press the "Setup (8) " button until the LED lights up permanently.
5.2.3 Use the device button to select the device to be operated (e.g. TV).
If the selection is successful, the LED flashes once and then lights up
permanently.
5.2.4 Press the "Power (13) " or "P+/P–" button to scroll through the preset
codes until the device to be operated shows a response.
5.2.5 Press "OK (5)" to save the code and back the code search. The LED goes
out.
5.2.6 Then test the remote control and check whether the desired functions
can be controlled. It is possible that the first code found is not the most
suitable, and possibly not all functions are available. In this case, repeat
steps 5.2.1. – 5.2.5. The code search starts with the next code following
the last one saved.
Note
A maximum of 350 codes of the most common devices can be stored in the
internal memory. Due to the numerous AV devices available on the market, it
may happen that only the most common main functions are available. If this is
the case, repeat steps 5.2.1 to 5.2.5 to nd a more compatible code. A code
may not be available for some speci c device models.
5.3 Automatic code search
The automatic code search uses the same preset codes as the manual code search
(5.2). However, the universal remote control automatically searches the codes
until the device to be operated shows a response. For example, the device to
be operated switches off ("Power (13) " button) or changes channel ("P+/P–"
buttons).
5.3.1 Switch the device you wish to operate on.
5.3.2 Press the "Setup (8) " button until the LED lights up continuously.
5.3.3 Use the device button to select the device to be operated (e.g. TV). If the
selection is successful, the LED flashes once and then lights up permanently.
5.3.4 Press the "P+/P–" or "Power (13) " button to start the automatic code
search. The LED flashes once and then lights up permanently. It takes 6
seconds for the universal remote control to start the first search.
4
Note: Setting the search speed
The default setting for the search time per code is 1 second. If this does not
suit you, you can change to a search time of 3 seconds per code. To switch
between search times, press "P+" or "P–" within the 6 seconds before the
automatic code search starts.
5.3.5 The LED confirms the respective code searches with a single flash.
5.3.6 As soon as the device to be operated shows a response, press the "OK (5)"
button to save the code and back the code search. The LED goes out.
5.3.7 Then test the remote control and check whether the desired functions
can be controlled. It is possible that the first code found is not the most
suitable, and possibly not all functions are available. In this case, repeat
steps 5.3.1. – 5.3.6.
The code search starts with the next code following the last one saved.
5.3.8 To cancel the automatic search during the search process, press the
"Back (12) " button.
Note
If all codes have been searched without success, the universal remote control
BACKs the automatic code search and automatically returns to operating
mode. The currently stored code remains unchanged.
5.4 Code recognition
Code recognition offers you the ability to determine a code you have already saved.
5.4.1 Press the "Setup (8) " button until the LED lights up continuously.
5.4.2 Use the device button to select the device to be operated (e.g. TV).
If the selection is successful, the LED flashes once and then lights up
permanently.
5.4.3 Press the "Setup (8) " button. The LED flashes once and then lights up
permanently.
5.4.4 Press one of the number buttons from 0 to 9 to search for the first digit.
The LED flashes once for the first digit of the five-digit code number.
5.4.5 Repeat step 5.4.4 for the second, third, fourth and fifth digits respectively.
5.4.6 You can then enter the determined code in the table below if you need
it again at a later time (e.g. after accidentally deleting the remote control
settings).
