USING THE OVEN

LEFT DISPLAY

ROTARY SWITCH KNOB
to navigate functions and adjust time
and duration parameters.
LIGHT
to switch the lamp on/off.
ON/OFF
to switch the oven on/off.
BACK
to return to the previous screen.
LEFT DISPLAY
This display shows the main cooking functions. The
selectable functions are displayed more brightly.
Symbols indicate the function. For a full
description see the table on page 17.

CONTROL PANEL DESCRIPTION

TOUCH KEYS KNOB

KNOB AND TOUCH KEYS

This display shows the clock, the details of
functions and helps to adjust temperature and
duration parameters.
For a full description of cooking functions, see the
table on page 17.
TOUCH KEYS

RIGHT DISPLAY

6 SENSE BUTTON KNOB
TH
to select, set, access, and confirm
functions or parameters and also start
the cooking program.
TEMP
to set the temperature.
START
to run cooking functions.
TIME
to set the clock, cooking duration or
extend the cooking cycle time.
RIGHT DISPLAY
EN 11
