EN 10

INSERTING WIRE SHELVES AND OTHER ACCESSORIES INTO THE OVEN

1. Insert the wire shelf horizontally, with the
raised part "A" upwards (Fig. 1).
2. Other accessories, such as the drip tray and
baking tray, are inserted in the same way as
the wire shelf (Fig. 2).
Partial and full extension sliding shelves facilitate the
handling of wire shelves and trays.
1. Remove the side holder grills (Fig. 1)
(with full extension sliders, it is necessary to first
remove the fixing screw).
2. Remove the plastic protection from the sliding
shelves (Fig. 2).
3. Hang the upper part of the sliders on to the
holder grills. Make sure the telescopic runners
can move freely to the front of the oven.
Then press the lower part of the sliding
shelves firmly against the holder grill until
they click into place (Fig. 3).
4. Refit the side holder grills to the cavity (Fig. 4).
5. Put the accessories on the slider (Fig. 5, 6).
MOUNTING THE SLIDING SHELVES (IF PRESENT)
Fig. 1
Fig. 2
1
2
Fig. 1
Fig. 3
Fig. 5
USING THE OVEN
Fig. 2
Fig. 4
Fig. 6
