Operation; Working Instructions; Inserting And Removing The Battery; Switching On And Off - Parkside Paexs 20-Li B2 Originalbetriebsanleitung

3. After charging, disconnect the battery
charger (14) from the mains.
4. Pull the battery (11) out of the battery
charger (14).

Operation

Working instructions

• Do not use the device without a dust
collection box or external dust extrac-
tion. Use of dust extraction can reduce
hazards caused by dust. When us-
ing sanding sheets without ventilation
holes, dust extraction is not possible.
Make sure that the workplace is well
ventilated.
• Move the appliance against the work-
piece once it is switched on.
• After machining, lift the sanding disc up
before turning off the device.
• Only work with sanding sheets in per-
fect condition to achieve good sanding
results.
• Work with low and even pressure and
even forward pressure. This protects the
appliance and the sanding sheet.
• Do not use the same sanding sheet to
sand different materials (e.g. metal and
then wood).
• Empty the dust collection box or the va-
cuum cleaner regularly in order to en-
sure optimal suction power.
Inserting and removing the
battery
WARNING! Risk of injury due to
unintentional start-up. Only insert the re-
chargeable battery into the device once
the device is fully prepared for use.
NOTICE! Risk of damage! An incorrect
battery can damage the device and bat-
tery.
Inserting the battery
1. Push the battery (11) along the guide
into the battery holder (1).
You will hear the battery click into
place.
Removing the battery
1. Press and hold the battery release (10)
on the battery (11).
2. Pull the battery out of the battery hold-
er (1).

Switching on and off

Switching on
1. Use the rotary wheel (4) to select a
speed level (1 ... 6).
2. Move the On/Off switch (3) forward
to the "I" (ON) position.
3. Wait until the device has reached full
speed.
4. Guide the sanding disc against the
workpiece.
Switching off
1. Remove the sanding disc from the
workpiece.
2. Move the On/Off switch (3) back to
the "0" (OFF) position.
3. Wait until the power tool has stopped
before placing it down.
4. Remove the rechargeable battery from
the device if you are leaving the device
unattended or if you have finished
working.

Transport

Information on transporting the device:
• Switch off the device and remove the
rechargeable battery. Make sure that
all moving parts have come to a com-
plete stop.
• Remove the attachment tool.
• Always carry the device by the handle
(2).
GB MT
33
