ENGLISH
Medical Device
DESCRIPTION
The device uses two different locking mechanisms to provide secure
suspension, mechanical and vacuum locking. It is offered in two versions,
with either a passive or active vacuum suspension.
Both locking mechanisms are released by pressing a single button,
making it easy to doff a prosthesis.
Components
A. Central Screw
B. Fixation Dummy
C. Distal Connector
D. Nails
E. Manufacturing Dummy 1
F. Manufacturing Dummy 2
G. Aluminum Dummy
H. Spacers
I. Flat-head Screws
J. Attachment Pin for Icelock 562
K. Lock Body
L. Large Square Ring
M. Large O-ring
N. Small Square Ring
