Keep a minimum distance of 3.3 m from such devices
when using this device.
Protect it from:
extreme temperatures
impact and dropping
contamination and dust
direct sunlight
heat and cold
If the device is not going to be used for a prolonged
period the batteries should be removed.
WARNING: The measurement results given by
this device is not a diagnosis. It is not replacing the
need for the consultation of a physician, especially
if not matching the patient's symptoms. Do not rely
on the measurement result only, always consider
other potentially occurring symptoms and the
patient's feedback. Calling a doctor or an ambu-
lance is advised if needed.
WARNING: This device is not a toy! Keep out of
reach of children and do not leave children alone
during use.
4
3. How this Thermometer measures
Temperature
This thermometer measures infrared energy radiated from
the forehead as well as objects. This energy is collected
through the lens and converted to a temperature value.
4. Control Displays and Symbols
All segments displayed 9: Press the START/IO
button 7 to turn on the unit; all segments will be shown
for 1 second.
Ready for measuring AT: When the unit is ready for
measuring, the «°C» or «°F» icon will keep flashing
while the mode icon (body or object) will be displayed.
Measurement complete AK: The reading will be
shown on the display 4 with the «°C» or «°F» icon
and the mode icon steady. The unit is ready for the next
measurement as soon as the «°C» or «°F» icon is
flashing again.
Low battery indicator AN: When the unit is turned on,
the icon will keep flashing to remind the user to
replace the batteries.
5. Setting Date, Time and Beeper Functions
Setting the date and time
1. After the new batteries are fitted, the year number
flashes in the display BO. You can set the year by
pressing the MEMO-button 5. To confirm and then
set the month, press the MODE button 6.
2. Press the MEMO-button 5 to set the month. Press the
MODE button 6 to confirm and then set the day.
3. Follow the previously mentioned instructions to set the
day, hours and minutes.
4. Once you have set the minutes and pressed the
START/IO button 7, the date and time are set and the
time is displayed.
If no button is pressed for 20 seconds, the device
automatically switches to ready for measuring AT.
Cancel time setup: Press the START/IO button
7 during time setup. The LCD will show Date/
Time icons with «--:--». After that press the
START/IO button 7 to start the measurement. If
no further action is taken within 30 seconds, the
device will automatically turn off.
