˜ Turning the rear handle
(Fig. C)
NOTE
If necessary, the rear handle
u
rotated 90° to the right or left to improve
your working position.
The arrow mark
u
rotation. Once the arrow mark
to the centre line of the cover for carbon
brushes , you hear a click sound. This
[ ]
means the rear handle
as it will go.
1. Press the lock button
2. Turn the rear handle
3. Release the lock button
˜ Saw blade information
Wood saw blade
1 ] [
Dimensions:
o
Materials:
o
o
o
o
Use:
o
o
Example:
o
˜ Inserting/removing the saw
blade
m WARNING!
Always switch the product off,
disconnect it from the mains and let the
product cool down before making any
adjustments!
m CAUTION! RISK OF INJURY!
Saw blades can be sharp and become
hot during use. Always wear protective
gloves when handling saw blades.
30 GB/IE
can be
[ 8 ]
indicates the extent of
5 ] [
is pointing
is rotated as far
8 ] [
.
[ 7 ]
to the right or left.
8 ] [
.
7 ] [
151 × 19 × 1.1 mm,
6 TPI
Wood
Plastic
Plaster
Other soft materials
Cut-off cuts
Plunge cuts
Cutting notches in light
construction walls
m CAUTION! RISK OF INJURY!
Do not use any blunt, bent or damaged saw
u
blade.
Always install a suitable saw blade for the
u
job.
Inserting the saw blade
(Fig. D)
1. Turn the chuck ring
direction.
2. Insert the saw blade into the saw blade
holder .
[ ]
3. Release the chuck ring
its original position. If necessary, turn the chuck
ring manually to its original position.
4. Before use: Pull on the saw blade and check if
it is inserted safely and tightly.
NOTE
For certain work, the saw blade can also be
u
inserted after turning it by 180° (Fig. D1:
Default position/Fig. D2: Alternative
position).
Removing the saw blade
(Fig. D)
1. Turn the chuck ring
direction.
2. Pull the saw blade out of the saw blade
holder .
[ ]
3. Release the chuck ring
original position.
˜ Setting the orbital action level
m CAUTION! RISK OF INJURY!
Only use the orbital action for cutting soft
u
wood such as pine. If you use the orbital
action to cut metal or other hard materials,
this will result in extremely high vibrations
and noise. The saw blade will jam and
break. The product will be damaged. There
is a risk of serious personal injury.
in a counter-clockwise
[ ]
and let it return to
[ ]
in a counter-clockwise
[ ]
and let it return to its
[ ]
