1 About this Document
This document is intended for qualified employees respon-
sible for installation and maintenance (installer, mainte-
nance technician, service, operator).
It contains information
•
for safe and appropriate handling of the product.
•
on function.
•
to technical data and maintenance.
•
for troubleshooting.
The original language of this document is German.
Information about ordering spare parts is not included.
See separate Parts Manual.
Programming instructions are not included. See separate
programming instructions for this.
Other Documents
Number Document
EU Declaration of conformity – CellTek
CE-1025
Programming Manual – Tightening Se-
P1730PM
quences
Programming Manual – S168813
P2280PM
mPro400GC(D) & mPro200GC(-AP)
Hardware Description – mPro400GCD-
P2309HW
M
Installation Instruction – mPro400GCD-
P2361JH
(...)
Installation Instruction – S168688 Live-
P2372JH
Wire Utilities
Hardware Description – mPro200GC(-
P2403HW
AP)
Programming Manual – S169263
P2544PM
CTBA & CTBP
Quick Installation Guide – CTBA &
P2545KA
CTBP Data Transmission
Parts Manual – CTBAW CellTek
SP12-1118
Parts Manual – CTBPW CellTek
SP12-1119
Respective Original Instructions Mil-
waukee Charger/Battery Pack
Symbols in the Text
italic Menu options (e.g., Diagnostics) input fields,
check boxes, radio buttons or dropdown menus.
> Indicates selection of a menu option from a
menu, e.g., File > Print.
<...> Specifies switches, pushbuttons or the keys of
an external keyboard, e.g., <F5>.
Courier Indicates Filenames and paths, e.g.,
setup.exe.
6
•
Indicates lists, level 1.
-
Indicates lists, level 2.
a) Indicates options.
b)
➢
Indicates results.
1. (...) Indicates action steps.
2. (...)
►
Indicates single action steps.
2 Safety
► Read all safety warnings and instructions. Failure to
follow the directions and safety instructions could re-
sult in an electric shocks, burns and/or serious inju-
ries.
► Keep this document in a safe place for future refer-
ence!
► These safety instructions must be accessible at all
times to all persons who use the product.
2.1 Warnings and Notices
Warning notes are identified by a signal word and a
pictogram:
•
The signal word describes the severity and probability
of the impending danger.
•
The pictogram describes the type of danger.
A symbol combined with the word Danger in-
dicates a hazard with a high level of risk
which, if not avoided, will result in death or
serious injury.
A symbol combined with the word Warning
indicates a hazard with a medium level of
risk which, if not avoided, could result in
death or serious injury.
A symbol combined with the word Caution in-
dicates a hazard with a low level of risk
which, if not avoided, could result in minor or
moderate injury.
Note
A symbol combined with the word Note indi-
cates a potentially harmful situation which, if
not avoided, could result in damage to prop-
erty or the environment.
General instructions include application tips and
useful information, but no warnings against haz-
ards.
