Problem
Tool not recognized.
Tool doesn't start with counter-
clockwise rotation activated.
Tool starts in tightening direction,
but not in counterclockwise rota-
tion.
Tool shuts off prematurely.
Tool does not change speed.
Warning in the Run Screen: Tool
offline!
Different torque display in the con-
troller and external transducer.
Apex Tool Group
Possible cause
Controller is waiting for tool ena-
blement.
Fast-Apps mode disabled.
Self-identification data are not rec-
ognized after tool change.
Software is incorrect.
FastApps mode is activated.
Tool is defective.
With counterclockwise rotation,
parameter for speed is set to
1
0 /min.
No speed programmed for coun-
terclockwise rotation.
Faulty reverse switch
Operator releases start trigger be-
fore the controller stops the tool.
The fastening time exceeds the
standard time of 10 seconds.
Tool exceeds the angle setpoint.
Speed is the same in all stages.
Tool has not been accepted in the
Tool Settings.
Adjust the torque calibration factor. 1.
Customer's special attachment
was added to tool. The tool
memory must be updated.
P2543BA | REV D l 2024-06
Measure
► Check FastApps. In the FastApps mode:
> .
► Enable the input Tool Enable or, if not re-
quired, deactivate Tool Enable.
► Enable FastApps mode:
.
Accept Tool Settings again:
1. Navigator > Tool Setup.
2. Select the line with the tool.
3. Select Tool Settings> Accept.
► Check controller and measuring card soft-
ware.
► Disable FastApps mode to connect to the
controller.
► Change tool.
Parameterize Speed left rotation
► Select on the controller Navigator >
Standard > Tool Groups > Settings For
Speed Left Rotation.
Parameterize Speed left rotation
► Select on the controller Navigator >
Standard > Tool Groups > Settings For
Speed Left Rotation.
► Replace Start/Reverse switch assembly.
► Make sure that the operator keeps the
start trigger pressed throughout the entire
sequence.
► Increase the fastening time.
► Check the fastening sequence to ensure
that the torque shutoff value and/or angle
setpoint are correct. Adjust as necessary.
► Check whether the fastening joint has
changed significantly.
► Make sure that the speed in the stages is
correct.
1. Select Navigator > Tool Setup.
2. Select the line with the tool in the tool list
and press <Tool Settings>.
3. Press <Accept>.
Select Navigator > Tool Setup.
2. Select the line with the tool in the tool list
and press <Tool Settings>.
3. Enter the torque calibration factor at
Torque Calibration using the following for-
mula:
New calibration value =
(external value / tool value) x calibration value
used.
Reprogram tool memory.
