Charger 18 V
Order No. Country
T50-1000499 North America
T50-1000506 Europe
T50-1000507 Brazil
T50-1000543 Argentina
T50-1000544 United Kingdom
T50-1000545 China
T50-1000546 Japan
T50-1000500 North America
T50-1000508 Europe
T50-1000547 United Kingdom
Working with controller (mPro-Modus)
► Configure the tool, refer to the Programming Manual
tool.
► Configure WLAN on the controller, refer to the Quick
Installation Guide and the Programming Manual
mPro(...)GCD.
Stand-alone (FastApp-Modus)
► Configure the tool, refer to the Programming Manual –
Cordless EC Tool.
8 Technical Data
8.1 Right Angle
Order no. Torque Range
Nm
(ft-lb)
Min.
CTBAW153 3.6
(2.7)
CTBAW213 5.2
(3.8)
CTBAW273 6.8
(5.0)
CTBAW383 10.0
(7.4)
CTBAW503 13.0
(9.6)
CTBAW653 17.0
(12.5)
Values without battery
3
Use of 80 % of maximum torque
Apex Tool Group
1-Bay
6-Bay
Nominal
Speed
Power
Nm
(ft-lb)
Max. W r/min
15.0 225 1025
(11.1)
21.0 225 735
(15.5)
27.0 225 560
(19.9)
38.0 225 395
(28.0)
50.0 225 285
(36.9)
65.0 225 220
(47.9)
P2543BA | REV D l 2024-06
7 Maintenance
Implement a comprehensive safety maintenance program
to provide regular inspection for all phases of tool opera-
tion and power supply.
Note
Loss of warranty
Repairs are only permitted by Apex Tool
Group authorized personnel. If the tool is
opened, the warranty is voided.
► If repair is required send the complete
tool to Sales & Service Center!
Maintenance Measures
after every ...
3
cycles
► Check all connections.
Daily
► Visual inspection for general dam-
age.
► Perform a general function test
and watch out for excessive vibra-
tion or unusual noise.
► Send the tool to a certified Sales &
500,000
Service Center for assessment.
or at least once
a year
Weight Length Height
kg mm mm
(lb) (in) (in)
1.40 515 38.7
(3.10) (20.28) (1.52)
1.40 515 38.7
(3.10) (20.28) (1.52)
1.40 515 38.7
(3.10) (20.28) (1.52)
1.55 525 44.5
(3.40) (20.60) (1.75)
1.60 534 43.8
(3.50) (21.02) (1.75)
1.70 543 46.8
(3.70) (21.38) (1.84)
1
EN
Side to
Output
Center
mm
(in)
14.3
3/8"
(0.56)
14.3
3/8"
(0.56)
14.3
3/8"
(0.56)
16.5
3/8"
(0.65)
17.0
3/8"
(0.67)
19.0
3/8"
(0.75)
