1
EN
Problem
Work light disabled.
Control menu on tool is not ena-
bled or only partially enabled.
No-load speed not reached.
Expected number of run-downs is
not achieved with one charge of
the battery.
Software does not boot.
WLAN data communication problems between controller and tool
Problem
No WLAN data communication be-
tween the controller and tool.
IP address cannot be pinged.
Occasional interruptions in WLAN
data communication.
14
Possible cause
Disabled by parameter setting.
Disabled by parameter setting.
Battery voltage is too low.
Battery is not fully charged.
The warning threshold for un-
dervoltage is not set to the mini-
mum value.
High torque is needed during a
fastening sequence, e.g., for
coated fasteners.
Battery has too many charging cy-
cles.
Error in the main software.
Possible cause
The IP address of the tool is not
correctly entered in the controller.
Tool is already assigned to an-
other controller.
IP address already exists in the
network. In this case, the tool will
not establish a connection.
Distance between the access point
and the tool is too great.
P2543BA | REV D l 2024-06
Measure
►
Parameterize the tool light on the control-
ler screen: Navigator> Advanced > Tool
Group > Extended Tool Settings.
► To activate the work light:
► Activate the control menu:
► Use a fully charged battery.
► Use fully charged battery.
► Reduce the Undervoltage (V) on the con-
trol screen: Navigator > Tool Setup > Tool
Settings > Others > Low Level [V].
► To set the warning threshold:
If a high torque is needed for a longer period of
time, e.g., for several turns, the number of run-
downs that can be achieved with one battery
charge will be significantly reduced.
After 800 charging cycles, the capacity is re-
duced to approx. 60%.
► Press the following keys:
► Use recovery SD card. Contact Sales &
Service Center, see back page.
Measure
1. Check on the control screen: Navigator >
Tool Setup, whether the IP address of the
tool has been entered in the box Type.
2. Otherwise, mark the line and <Edit>.
IP address of tool – see Tool in submenu
WLAN communication.
► Check the WLAN settings and make sure
that the WLAN settings for the controllers
are different.
Applies only to WLAN infrastructure custom-
ers:
► Check whether another controller already
has a connection to this tool. In other
words, another controller is using the
same IP address.
► Check the physical connection (RSSI val-
ues): >
► Check the assigned IP address.
1. Check signal strength at tool in the sub-
menu Signal Strength:
2. If necessary, reduce the distance between
the access point and the tool.
>
>
>
>
