Endress+Hauser Proline Promass O 100 Technische Information Seite 60

60
Flanschanschlüsse
Festflansch ASME B16.5
Längentoleranz Maß L in inch:
• DN ≤ 4": +0,06 / –0,08
• DN ≥ 6": ±0,14
Flansch in Anlehnung an ASME B16.5: Class 900 Schedule 40
Rostfreier Stahl, 1.4410/F53 25Cr Duplex (Super Duplex)
Bestellmerkmal "Prozessanschluss", Option ADD
DN A
[in] [in]
3 9,45
4 11,42
6 14,96
Flansch in Anlehnung an ASME B16.5: Class 1500 Schedule 80
Rostfreier Stahl, 1.4410/F53 25Cr Duplex (Super Duplex)
Bestellmerkmal "Prozessanschluss", Option AFD
DN A
[in] [in]
3 10,43
4 12,20
6 15,55
RTJ-Flansch in Anlehnung an ASME B16.5: Class 900 Schedule 40
Rostfreier Stahl, 1.4410/F53 25Cr Duplex (Super Duplex)
Bestellmerkmal "Prozessanschluss", Option AED
DN A
[in] [in]
3 9,45
4 11,42
6 14,96
D
B C
[in] [in]
7,5 8 × Ø1,0
9,25 8 × Ø1,25
12,5 12 × Ø1,25
B C
[in] [in]
8 8 × Ø1,0
9,5 8 × Ø1,38
12,5 12 × Ø1,50
B C
[in] [in]
7,5 8 × Ø1,0
9,25 8 × Ø1,25
12,5 12 × Ø1,25
Proline Promass O 100
L
D E
[in] [in] [in]
1,78 3,07 37,87
2,02 4,03 49,25
2,46 6,07 59,57
D E
[in] [in] [in]
2,16 2,9 39,09
2,39 3,83 50
3,53 5,76 62,09
D E
[in] [in] [in]
1,81 3,07 37,91
2,06 4,03 49,29
2,5 6,07 59,65
Endress+Hauser
A0023178
L
L
L
