BEZZERA MODA PM – DE – DE+D – DE+D+M
MOD.
Power supply
Heating element
Nominal power
Width "A"
Depth "B"
Height "C"
Net weight
Gross weight (pallets)
Water input connector
Drain connector

4 - MACHINE INSTALLATION

4.1 Warnings

Installation must be carried out by qualified per-
sonnel, according to the instructions supplied by
the manufacturer and in compliance with current
laws.
The machine must be positioned and installed
in a place where use and maintenance are per-
formed exclusively by qualified personnel. The
machine can be used in places set up for staff
kitchen areas in shops, offices and other working
environments; holiday farm houses; by clients in
hotels, motels and other types of accommoda-
tion; bed and breakfast settings; etc.
4.2 Preparation of system for
installation
Place the machine on a flat, horizontal, even, dry,
smooth, sturdy, stable surface positioned at such
a height that the cup warming surface is over 150
cm from the ground. Do not use water jets or in-
stall in places where water jets are used.
To ensure normal operation, the appliance must
be installed in places where the temperature is
between +5°C and +32°C and the humidity
does not exceed 70%.
If the machine is exposed to temperatures below
+ 0°C, proceed as follows:
- ensure that the machine has spent 24 hours
in a location where the temperature is above
+15°C before switching it on.
The machine is electrically powered and requires
the following for its operation:

- connection to mains electricity.

- connection to mains water.
- connection to drainage circuit.
Moda PM
3 Groups
V-/Hz 230-400
W 5020
W 5600
mm 960
mm 550
mm 515
Kg 74
Kg 86
36
Moda DE
3 Groups
230-400
5020
5600
960
550
515
74
86
G 3/8"
4.2.1 Connection to mains electricity
Warnings:
- The connection to the mains must be made by
qualified personnel.
- The wiring must be done in compliance with
current laws and earthed.
The machine is supplied with a power cord with-
out a plug; for a permanent electrical connection
between the appliance and the mains electric-
ity, fit a safety omnipolar switch with a minimum
opening between the contacts of overvoltage cat-
egory III, suitably sized for the load and in compli-
ance with the current regulations in force.
4.2.2 Connection to mains water
(Fig. 03)
Make sure that the water supply line is connected
to a drinking water network with operating pres-
sure between 0 and 6 bar (0 - 0.6 MPa).
If the water network has pressures above 6 bar
(0,6 MPa), install a pressure reducer.
Install a water shut-off valve upstream of the ma-
chine's connection.
The water inlet pipe (Fig. 03; pos. 1) has a G
3/8" thread.
Warning:
Do not open the screw-on cap and
boiler exhaust valve: risk of scalding.
Use only the new inlet pipe supplied.
Moda DE+D
3 Groups
230-400
5020
5600
960
550
515
74
86
