Motor Confi guration Parameters
P028 Selection type of operators
TYPE 00
• 005: LIVI_6/24 - 6/24 BOOST
• 006: LIVI_9/24
TYPE 01
• 000: GEKO
• 001: LOOK - MAC - STING
TYPE 02
• 003: LIVI 902/24 - 905/24
TYPE 03
• 003: PASS 24_N
P029 Selected work with or without encoders
WARNING: Remember to correctly set the jumpers J5 and J9 (see board terminal
table)
WARNING: J5, J9 and P029 must be set correctly before performing the procedure
for programming
P030 Selectioning operators number
• 001: one operator
• 002: two operators
Operating Parameters
P031 Operators speed adjustment during slow-down while opening
P032 Operators speed adjustment during the stroke while opening
P033 Operators speed adjustment during the stroke while closing
P034 Operators speed adjustment during slow-down while closing
P035 Slow down duration adjustment while opening
P036 Slow down duration adjustment while closing
P037 Operator 1 force adjustment while opening
if = 100% obstacle detection deactivated
P038 Operator 1 force adjustment while closing
if = 100% obstacle detection deactivated
P039 Operator 2 force adjustment while opening
if = 100% obstacle detection deactivated
TYPE 02 ONLY: Secondary force adjustment in closing: adjusts the motor's force
during the last part of the closing movement defi ned by P058.
P040 Operator 2 force adjustment while closing
if = 100% obstacle detection deactivated
P041 Automatic closing times adjustment
if = 0 automatic closing deactivated
P042 Pedestrian automatic closing time adjustment
if = 0 pedestrian automatic closing deactivated
P043 Pedestrian stroke duration adjustment
• 007: REV24
• 008: REV24 BOOST
• 002: GHOST 100 - GHOST 200
• 003: LIVI 502/24 - ANGOLO
• 004: LIVI 902R/24
• 004: STOP 24_N
Default TYPE
00 01 02
005 005 003
• 004: LIVI 502MT/24
• 005: GEKO/X
001 001 000
• 000: motors with encoder
• 001: engines without encoder
001 002 001
Default TYPE
00 01 02
040 050 050
15%..................100%
100 100 100
15%..................100%
100 100 100
15%..................100%
040 050 050
15%..................100%
025 020 020
0%..................80%
025 020 020
0%..................80%
050 050 050
15%..................100%
050 050 050
15%..................100%
050 050 000
15%..................100%
0%..................100%
050 050 000
15%..................100%
000 000 000
0s..................255s
000 000 000
0s..................255s
030 035 035
5%..................100%
NET24N
03
003
000
001
03
030
100
100
030
030
030
099
099
099
099
000
000
100
