PRODUCT DIAGRAM
Robot
Navigation Module
Obstacle
Avoidance Module
Buttons
Short Press: Return to charge
Short Press: Start/Pause/Continue
Short Press: Start/End Spot Clean
RESET Button
Connect to App: Short-press RESET Button and follow voice prompts to connect to the App.
Restore to default settings: Press and hold RESET Button for 5 s. After you hear the voice
prompt, the startup music will be played and the robot will be restored to default settings.
Charging
Contacts
EN 8
Top Cover
Buttons
Bumper
Long Press: Power on/off
Long Press: Child Lock
Data Transfer Port
For professional
maintenance personnel
use only.
Status Indicator
Edge Sensor
Bottom View (
DKX55
Anti-drop Sensor
Carpet
Detection Sensor
Brush
Vacuum Module
OZMO Pro 2.0 Vibrating Mopping System
Reservoir
Washable Mopping Pad
Wi-Fi
Dust Bin
Filter
Sponge Filter
)
Universal Wheel
Side Brush
Brush
Release Button
Driving Wheels
Water Inlet
Reservoir
Release Button
Dust Bin Handle
Filter Net
Release Button
