CHARGE DEEBOT
Short press to recall DEEBOT to enter the Docking Station to charge.
6.5
Short press
OPERATE DEEBOT
Remove the Mopping Pad Plate/Module before mapping. When creating a map for the
first time, please follow DEEBOT to help eliminate some minor issues.
For example, DEEBOT may get stuck under the furniture. Please refer to the
following solutions:
① Raise your low sitting furniture if possible;
② Cover the bottom of the furniture;
③ Set up Virtual Boundary via the App.
Before first vacuuming, please make sure DEEBOT is in the Docking Station
and fully charged. Short press to start cleaning and mapping.
Short press
Note:
• Do not frequently remove washable mopping pads.
• Do not use a rag or any other object to scratch the Moping Pad Plate.
• When the ECOVACS HOME App prompts that the mopping pad needs to be
replaced, please replace it in time. Explore more accessories at ECOVACS
HOME App or at https://www.ecovacs.com.
TECHNICAL SPECIFICATIONS
Model
Rated Input 20 V
Docking Station
Rated Input
Rated Output
DEEBOT Dimensions
(L*W*H mm)
Docking Station
Dimensions
(L*W*H mm)
Output power of the Wi-Fi module is less than 100 mW.
Note: Technical and design specifications may be changed for continuous product improvement.
Explore more accessories at https://www.ecovacs.com.
DKX55/DKX56
1 A Charging Time 6.5 h
CH2405
100-240 V ~ 50-60 Hz 0.5 A
20 V 1 A
353*351*96
218*73*111
Please use the mobile camera
to scan the QR code and
obtain the user guide.
