EN
Wear gloves and be careful with sharp edges.
Apply the guard to the blade.
Use the specified Nylon locknut which is packed with
the blade, to assemble the blade.
Make sure that you can not turn the locknut by hand.
You must replace the locknut after it has been put on
approximately 20 times.
1. Put the gear box on a flat surface to make sure
that the blade is assembled correctly.
2. Turn the center shaft until one of the holes in
the inner cup aligns with the specified angle
transmission hole in the gear box.
3. Put the metal rod in the specified angle
transmission hole to fix the center shaft.
4. Put the brush cutter blade on top of the inner cup.
Make sure the blade is in the center.
5. Put the outer cup above the blade.
6. Put the locknut above the outer cup.
7. Tighten the locknut counter-clockwise which is
the opposite direction of rotation with a wrench.
6.8 REMOVE THE BRUSH CUTTER BLADE
Figure 29 - 32.
1. Put the metal rod in the specified angle
transmission hole.
2. Turn the blade and push the metal rod until
it engages one of the holes in the inner cup,
blocking rotation.
3. Loosen the locknut clockwise which is the
direction of rotation and remove it.
4. Remove the outer cup.
5. Remove the brush cutter blade. Do not remove
the inner cup from the shaft.
6.9 ASSEMBLE THE TRIMMER HEAD
Figure 33 - 34.
1. Put the metal rod in the specified angle
transmission hole to fix the trimmer head.
2. Assemble the trimmer head.
3. Turn the trimmer head counterclockwise to
tighten it.
WARNING
WARNING
WARNING
WARNING
English
4. Remove the metal rod.
You must install the cut-off blade when you use the
trimmer head.
6.10 SHARPEN THE BRUSH CUTTER BLADE
Figure 35
Stop the machine and remove the battery pack(s).
Use protective gloves.
Always discard a blade that is damaged. Do not try
to make a bent or twisted blade straight and use it
again.
We recommend that a service center which has
electric sharpener does the high level or important
sharpening work.
• Sharpen all edges equally to keep the balance.
• Use a single-cut flat file.
7 TRANSPORTATION AND STORAGE
7.1 MOVE THE MACHINE
When you move the machine, you must:
• Wear gloves.
• Stop the machine.
• Remove the battery pack(s).
• Assemble the blade guard.
7.2 STORE THE MACHINE
• Remove the battery pack(s) from the machine and
charge it.
• Make sure that children cannot access the machine.
• Keep the machine away from corrosive agents such
as garden chemicals and de-icing salts.
• Secure the machine during transportation to prevent
damage or injury. Clean and examine the machine
for any damage.
8
IMPORTANT
WARNING
WARNING
NOTE
