2. Remove the blade screw(s) from the cut-off
blade.
3. Turn the cut-off blade 180°.
4. Tighten the blade screw(s).
6 MAINTENANCE
IMPORTANT
Read and understand the safety regulations and the
maintenance instructions before you clean, repair or
do the maintenance work on the machine.
IMPORTANT
Make sure that all nuts, bolts and screws are tight.
Check regularly that the handles are firmly mounted.
IMPORTANT
Use only the replacement parts and accessories of
the initial manufacturer.
6.1 GENERAL INFORMATION
IMPORTANT
Only your dealer or approved service center can do
the maintenance that is not given in this manual.
Before the maintenance operations:
• Stop the machine.
• Remove the battery pack(s).
• Cool the motor.
• Use correct clothing, protective gloves, and safety
glasses.
6.2 CLEAN THE MACHINE
• Clean the machine after each use with a moist cloth
dipped in neutral detergent.
• Do not use aggressive detergents or solvents like
"glass cleaner" to clean the plastic parts or handles.
• Keep the trimmer head free from grass, leaves, or
excessive grease.
• Keep the air vents clean and free of debris to avoid
overheating and damage of the motor.
• Do not spray water onto the motor and electrical
components.
6.3 REMOVE THE REMAINING LINE
Figure 15 - 17.
1. Simultaneously press the tabs on the sides of the
trimmer head.
2. Pull and remove the spool cover.
3. Remove any remaining line.
English
4. Clean dirt and debris from all parts.
5. Align the spool tabs with the tab openings in the
base of the spool.
6. Push the spool cover until it clicks into position.
6.4 REPLACE THE SPOOL
Figure 18.
If any parts of the spool retainer assembly are
damaged or worn, replace the damaged part and
reassemble them as following showing
1. Disassemble the trimmer head. Pull and remove
the spool cover.
2. Clean dirt and debris from all parts.
3. Loosen the screws. Remove the spool, slot cover,
location housing from the spool assembly.
4. Replace with a new spool.
5. Insert the location housing and slot cover onto the
spool cover, and then put the spool onto the slot
cover to the desired position.
6. Tighten with the screws.
6.5 INSTALL THE CUTTING LINE
Figure 19 - 23.
Do not put more than 15 feet of cutting line in at a
time.
1. Line up the slots on the spool cap with the slots
on the trimmer head.
2. Put the cutting line through the hole. Push the
cutting line until it exits the opposite hole.
3. Pull the cutting line through until there is an equal
quantity of cutting line on each side.
4. Turn the spool cap clock-wise to wind the cutting
line into the trimmer head. Keep approximately 5
in of cutting line above out of each side of the
trimmer head.
6.6 REMOVE THE TRIMMER HEAD
Figure 24 - 26.
1. Put the metal rod in the specified angle
transmission hole.
2. Turn the trimmer head and push the metal rod
until it engages one of the holes in the inner cup,
blocking rotation of the center shaft.
3. Turn the trimmer head clockwise to loosen it.
6.7 ASSEMBLE THE BRUSH CUTTER BLADE
Figure 27 - 28.
7
