EN
2. Tap Scheduler Mode.
3. Tap Scheduler Mode to toggle the function on or off.
6.4.2 Enabling or disabling a program
Scheduler mode must be turned on to run programs. Programs and their scheduled
actions will be shown on the Program screen.
1. On the Home screen, tap Main Menu.
2. Tap Scheduler Mode.
3. Tap Programs.
4. Use the Up Arrow or Down Arrow to navigate to the program.
5. Tap the program menu bar to enable or disable the program.
6.4.3 Editing a program
Program options include setting the mode, functions, temperature set point, and the
time and days of the week the program will run once turned on.
1. On the Home screen, tap Main Menu.
2. Tap Scheduler Mode.
3. Tap Programs.
4. Use the up arrow or down arrow to navigate to the desired program screen.
5. Tap Edit.
6. Tap Cool, Heat, Auto, or Off to select the mode, then tap the down arrow to
move to the next screen.
7. Tap Eco and/or Quiet to turn these functions on or off, then tap the down arrow.
These functions will not be available if the mode selected in the earlier step was
"Off". Both can be set to on or off, as desired.
8. Tap the le arrow or right arrow to set the temperature, then tap the down arrow.
9. Tap the le arrow or right arrow to set the time, then tap the down arrow.
10. Tap one or more days to set which days the program will run.
11. Tap the Save icon to save the program.
6.5 Parameters
The selections in the Parameters menu are used to set up and adjust the system
parameters. To navigate to the Parameters menu:
1. From the Home screen, tap Main Menu.
2. Tap Parameters, then use the Up Arrow and Down Arrow to scroll through the se-
lections.
Selection Description
Memorize Setting This selection memorizes the current set-
tings for all parameters providing a sys-
tem-wide point that can be returned to
when troubleshooting.
Recall Memorized This selection returns all parameters to the
last memorized settings.
Recall Factory This selection returns all parameters to
their factory settings.
High Fan Speed This selection adjusts the fan speed on the
high setting reducing the air noise pro-
duced by the system.
6
Selection
Low Fan Speed
Fan Operate
Mode
Pump Operate
Mode
Inside Temp Cali-
brate
Temperature Units This selection toggles temperature read-
Pressure Units
Aux Electric Heat
Filter Hours Set-
ting
Filter Hours Reset
Actions
1. Tap Memorize Set-
tings.
2. Tap Yes.
Filter Alarm Delay
3. Tap OK.
1. Tap Recall Memo-
rize.
2. Tap Yes.
3. Tap OK.
Zone/Area
1. Tap Recall Facto-
ry.
2. Tap Yes.
3. Tap OK.
1. Tap High Fan
Speed.
Set Point Temp
2. Tap the Le Arrow or
Differential
Right Arrow to adjust the
maximum fan speed per-
centage.
3. Tap Save.
Description
This selection adjusts the fan speed on the
low setting ensuring the fan speed is high
enough to overcome the static pressure in
ductwork.
Selecting Continuous keeps the fan run-
ning at slow speed when the compressor
cycles off. Selecting Cycled turns the fan
off and on with the compressor.
Selecting Continuous keeps the pump
running continuously when the compres-
sor cycles off. Selecting Cycled turns the
pump off and on with the compressor.
This selection is used to calibrate the cab-
in temperature reading when it is consis-
tently different from the actual tempera-
ture.
outs between °F and °C and affects all
temperature screens. The default is °F.
This selection toggles pressure readouts
between psi, Kpa, or bar and affects all
pressure screens. The default is psi.
This selection activates the auxiliary elec-
tric heater relay if one is connected. It will
only work in place of the reverse heating
cycle and not as a supplementary heat
source. The default is off. The appropriate
power rating must be selected to activate
the heater.
When activated, this selection indicates
when the filter is ready to be replaced
as determined by the selected filter life
range. The default is off.
This selection resets the filter life counter
to zero. The filter hours should be reset
when the filter is replaced or cleaned.
This selection is not available when Filter
Hours Setting is set to off.
This selection sets the duration to snooze
the filter alarm when Snooze is used in the
Filter Alarm screen.
This selection assigns a zone name to one
or more units. For networked units, this al-
lows a command from one display to con-
trol all units assigned to that zone. The de-
fault for all units is Master Stateroom.
This selection adjusts the temperature dif-
ferential between the set point and the
cabin temperature reading which is used
to decide when the system cycles on.
Actions
1. Tap Low Fan Speed.
2. Tap the Le Arrow or
Right Arrow to adjust the
minimum fan speed per-
centage.
3. Tap Save.
1. Tap Fan Operate
Mode.
2. Tap Continuous or Cy-
cled.
1. Tap Pump Operate
Mode.
2. Tap Continuous or
Cycled.
1. Tap Inside Temp
Calibrate.
2. Tap the Le Arrow or
Right Arrow to adjust the
reading.
3. Tap Save.
Tap Temperature Units to tog-
gle between °F or °C.
1. Tap Pressure
Units.
2. Tap the Le Arrow or
Right Arrow to adjust the
reading.
3. Tap Save.
1. Tap Aux Electric
Heat.
2. Tap the Le Arrow or
Right Arrow to scroll
through the options.
3. Tap Save and follow the
prompts to confirm the
selection.
1. Tap Filter Hours
Setting.
2. Tap the Le Arrow or
Right Arrow to scroll
through the options.
3. Tap Save.
1. Tap Filter Hours
Reset.
2. Tap Yes.
3. Tap OK.
1. Tap Filter Alarm
Delay.
2. Tap the Le Arrow or
Right Arrow to adjust the
reading.
3. Tap Save.
1. Tap Zone/Area.
2. Tap the Le Arrow or
Right Arrow to scroll
through the list of
zones/areas.
3. Tap Save.
1. Tap Set Point Temp
Differential.
2. Tap the Le Arrow or
Right Arrow to scroll
through the list of set-
tings.
3. Tap Save.
