Icon Control/indi-
cator
Main menu con-
trol
Mode control
Fan speed con-
trol
Table 2: Additional controls
Icon Control/indi-
cator
Cancel
Clear
CLR
Edit
E dit
OK
OK
Return home
Save
6.2 Eco mode
When Eco mode is on, the system will not exceed the maximum power consumption
limit set in the Eco Mode Set Point screen. If the system is operating above the set limit
when Eco mode is turned on, the system will gradually slow down until power consump-
tion is below the limit.
Description
The Main menu is used to set up, schedule, and trou-
bleshoot the system.
Tap to display the first Main menu screen, then tap
the Down Arrow to display the second Main Menu
screen.
Tap to cycle through Cool, Heat, Auto, and Fan Only.
This control is only available when the system is in
Fan Only mode. Refer to Parameters on page 6
to learn how to adjust the fan speed settings.
Tap to cycle through the fan speeds: Low, Medium,
and High
Description
Tap to cancel an entry or to return to the earlier
screen.
Tap to clear the current entry.
Tap to make changes in the current screen.
Tap to confirm an entry.
Tap to return to the Home screen.
Tap to save an entry.
NOTE Eco mode and Quiet mode can be active at the same time. The sys-
tem will operate at the set point that is the lowest. Be advised that setting the
set point too low can affect the system's cooling capability.
6.2.1 Turning Eco mode on or off
1. On the Home screen, tap Main Menu.
2. Tap Function.
3. Tap Eco Mode to toggle the function on or off.
The Eco Mode indicator will display on the Home screen if the mode on.
6.2.2 Adjusting the Eco mode set point
1. On the Home screen, tap Main Menu.
2. Tap Function.
3. Tap Eco Mode.
4. Tap the down arrow.
5. Tap Eco Mode Set Point.
6. Tap the le arrow or right arrow to adjust the set point.
7. Tap Save.
The Eco Mode indicator will display on the Home screen if the mode on.
6.3 Quiet mode
Quiet mode limits noise and turns off the display for nighttime operation. The system will
operate below the maximum compressor speed set in the Quiet Mode Set Point
screen.
NOTE Eco mode and Quiet mode can be active at the same time. The sys-
tem will operate at the set point that is the lowest. Be advised that setting the
set point too low can affect the system's cooling capability. Quiet Mode
will automatically turn off if the temperature is more than 3 °F (1.8 °C) from the
set point.
6.3.1 Turning Quiet mode on or off
1. On the Home screen, tap Main Menu.
2. Tap Function.
3. Tap Quiet Mode to toggle the function on or off.
The Quiet Mode indicator will display on the Home screen if the mode on.
6.3.2 Adjusting the Quiet mode set point
To find the best set point, slowly decrease the set point percentage until the desired
noise level is reached.
1. On the Home screen, tap Main Menu.
2. Tap Function.
3. Tap Quiet Mode.
4. Tap the down arrow.
5. Tap Quiet Mode Set Point.
6. Tap the le arrow or right arrow to adjust the set point.
7. Tap Save.
The Quiet Mode indicator will display on the Home screen if the mode on.
6.4 Scheduler mode
Scheduler mode can automatically run up-to-four programs once they have been set up
and activated. Programs can be set for desired days and times and include modes, func-
tions, and temperatures.
6.4.1 Turning Scheduler mode on or off
Scheduler mode must be turned on to run or edit programs.
1. On the Home screen, tap Main Menu.
