Use
NOTE
► In addition to the items supplied, you will require a drill or a cordless
screwdriver and an additional clamp in order to use the product.
Measuring wood thickness (Fig. A)
♦ Press the limit stop on the drilling jig
♦ Place the drilling jig
the wood thickness.
Setting the wood thickness (Fig. B)
♦ Set the measured wood thickness on the drilling jig
following table.
Wood thickness
12–18 mm
19–26 mm
27–37 mm
♦ Hold down the knob and push the drilling jig
setting is reached.
♦ Release the knob once the drilling jig
PSVH 56 A1
against the wooden workpiece and read off
≥ 38 mm
downwards.
using the
Setting
12
19
27
38
until the required
is engaged.
