2.
Technical data and functional description
2.1
Technical data
Article
Model
11410904
F7508
11410905
F7510
11410914
F9008
11410915
F9010
* Measured according to ISO 1217; ** Measured according to ISO 3744
2.2 General description
The F-Series oil-filled screw compressor series is designed for uninterrupted and efficient-
compressed-air production.
The F-Series compressor is an electric motor-operated, intake-regulated, belt-driven and air-
cooled compressor, enclosed in a sound-insulated canopy. An electronic controller i-Log with
an LCD indicator panel is provided, including start and stop buttons and an emergency stop
button. Pressure and temperature relays are used for system control and protection.
COMPRAG
Screw air compressor F-Series
Entitlement to free handling of faults arising during the guarantee pe-
riod is forfeited when:
- No warranty service coupon for the compressor or it is filled out
incorrectly
- No records for the compressor's scheduled maintenance are entered
in the compressor's service book
- Unoriginal parts and lubricants are used
Max. operat-
ing pressure
(bar)
5-8
75
5-10
5-8
90
5-10
Rated
Output*
voltage,
(m ³ /min)
compressor
(phase/V/Hz)
12,40
10,80
3/380/50
14,70
12,80
Screw
capacity,
connection
liter***
75
2"
75
Oil
35
9
