21°C
0.00HZ
0.0BAR
0RPM
STOP
C01
LOKAL
Main menu: Click
RUN PARAMETERS
USAGE PARAM
FACTORY PARAM
ADJUST. PARAM
Description of the parameters. Run parameters:
Select the run parameters using the up
are displayed.
M1 AND FAN CUR
TOTAL RUN TIME
THIS RUN TIME
MAINTEN. PARAM
ERRORS HISTORY
SERIAL NUMBER
THIS ERROR
COM. STATUS
The other menus have a similar structure.
Select the line " M1 AND FAN CUR " and press
M1(A) AND FAN(A)
A: 000.0 000.0
B: 0.0
0.0
C:0.0
0.0
TOTAL RUN TIME
TOTAL RUN TIME:
TOTAL LOAD TIME:
THIS RUN TIM
THIS RUN TIME:
THIS LOAD TIME:
COMPRAG
Screw air compressor F-Series
in order to bring up the options menu:
Includes current values (available for viewing)
Includes operating settings of the main parameters (available for viewing,
changes password-protected)
For servicing mode (view with password). Modification only possible by manufacturer
Basic settings and maintenance hour counter (Password protected)
Phase current of main motor and fan motor
Total running hours (main engine running).
Total operating time under load (main engine running+ suction valve open).
The current operating time from the last start.
Current running time under load
and down
buttons and enter
.
. Current values
19
