● The product must only be used for its intended purpose.
● Stop the product and remove the battery before it is left
unattended.
● Stop the product and remove the battery if the product
operates abnormally.
● Inspect the product before use. Make sure that all screws
are tightened and that moving parts do not jam.
● Do not operate the product in a place where objects can
get stuck and be thrown out by the product. Ejected
objects can cause serious personal injury and/or material
damage.
● Stop the product and make sure that all moving parts
have stopped before you put the product down.
● Do not attempt to stop the product with your hands.
● Always hold the product in its designated handles.
● Only operate the product in daylight.
● Make sure to keep your balance at all times.
● Do not run with the product.
● Make sure that the ventilation openings on the product
are free from debris.
● Do not use the product with metallic blades.
3

Assembly

Warning! Do not attach the battery until the product
is fully assembled.
3.1 To attach the trimmer guard and
distance wheel
Figure 2
1
Put the trimmer guard onto the motor unit and attach
it with the 2 screws.
2
Put the distance wheel onto the trimmer guard and
attach it with the 2 screws.

3.2 To attach the front handle

Figure 3
1
Remove the front handle screw.
2
Pull the ends of the handle apart lightly.
3
Put the handle onto the handle holder.
4
Attach the front handle screw.
30
4

Operation

4.1

To replace the trimmer spool

Figure 4
1
Remove the battery from the product.
2
Push the locking tabs on the trimmer head and
remove it.
3
Remove the old trimmer spool.
4
Put the 2 trimmer lines of the new trimmer spool
through the 2 trimmer line outlets.
5
Put the trimmer spool inside the trimmer head.
Note! The side of the trimmer spool with arrows must be
visible when you have installed it inside the trimmer head.
6
Put the trimmer head back into the trimmer head slot.
Make sure that the trimmer head clicks into place.

4.2 To replace the trimmer blades

Figure 5
1
Remove the battery from the product.
2
Push the locking tabs on the trimmer head to remove
the trimmer head.
3
Push the 2 trimmer blades inwards to release them
from the locking pins.
4
Remove the trimmer blades from the trimmer head.
5
Open the ring on the rear handle (A) and take out 2
new trimmer blades.
6
Put the 2 trimmer blades onto the locking pins on the
trimmer head and pull them outwards to lock them in
place.
7
Put the trimmer head back into the trimmer head slot.
Make sure that the trimmer head locks into place.
