3 Description
3 .1 Function
With the AWG turbo nozzles EVO, a full jet or a spray jet from 0° to 120°
can be generated at a selectable flow rate.
The extinguishing agent discharge is started and stopped with the hand lever.
By turning the nozzle head (jet form sleeve) the spraying angle is changed
between full jet and the different settings for the spray jet.
Full jet
Spray jet
Rinsing
For models with a fixed sprocket in the jet form sleeve, the sprocket
ensures a filled spray cone by reflecting the water droplets. With models
without a fixed sprocket, no water droplets are reflected, a hollow conical
spray is created (hollow jet).
The turbo wheel (optional), which rotates quickly in the spray jet, is used
for fine atomisation of the spray jet.
Extinguishing foam can be produced with an optional foam attachment.
With the optional FIRE-EX Turbo 1000 wetting agent cartridge, wetting
agent is generated directly in the hollow nozzle and applied with the turbo
nozzle EVO.
3 .2 Intended use
>
Fire-fighting with both full jet and spray jet
>
When used with foam agent (with foam attachment accessory): fighting
fires involving non-polar liquids (petrol, oil)
Only use the device in technically sound condition and in accordance
with the intended purpose and with safety and potential dangers in mind.
31
If the jet pipe head is in the full jet position, a focused jet with
a long throwing distance and corresponding mechanical pe-
netration force of the water flow is achieved.
In the other positions of the nozzle head, an atomised spray
jet covering an area is generated. The spectrum ranges from
a concentrated spray pattern to a wide filled spray cone.
In this position, dirt particles can be removed from the nozzle
in the direction of flow.
