3. THE CONTROLS
L C D
screen
Menu control
buttons
BID socket
Adaptor lead
3.1

USING THE CONTROLS

The three buttons on the Power Peak ULTIMATE 2 are multi-purpose controls, as indica-
ted by the printed legends. Pressing the buttons performs different actions depending on
the selected mode of operation.
'-' / MODE / AUTO BUTTON
• In Manual mode and in Set-up mode this button is used to reduce the value of the
selected charge parameter by one increment; in Menu Select mode it selects the pre-
vious menu.
• By pressing the 'MODE' button you can select the desired process (CHARGE, DISCH-
ARGE or DISCHARGE ‡ CHARGE) directly before the start.
• When the power supply has been connected, this button is used in the Select menu
to activate "Automatic mode" (AUTOMA.).
'+' / START / MAN BUTTON
• In Manual mode and in Set-up mode this button is used to increase the value of the
selected charge parameter by one increment; in Menu Select mode it selects the next
menu.
• Pressing the 'START' button initiates the selected process, e.g. CHARGE.
• When the power supply has been connected, this button is used in the Select menu
to activate "Manual mode" (MANUAL).
Operating instructions
POWER PEAK ULTIMATE 2
BID chip
Temperature-control-
led cooling fan
Battery con-
nection socket
6
No.
8470
Power
supply
