This error message inform you that the fixture was overheating (occured if the ambient temperature is 55°C or
more) and that the relay switched Off the lamp. This message will shine on the display until the temperature will
be on the suitable level, then on the display will appear the HEAt message meaning the lamp is too hot. (explanation
see above).
This message appears if the lamp lighting sensor is failed. Please, contact your dealer.
This message will appear if the fixture was shortly disconnect from the main.
It will appear if the frequency of the main is not standard 50 or 60Hz.
Power supply:
230 V/50 Hz
Power consumption:
800 W, Fuse: T5A
Lamp:
HMI 575
Optical System
- Double condensor lens with high efficiency parabolic mirror
Colours
- 11 interchangeable dichroic-filters plus white
- Colour-wheel with variable rotation speed
Static gobos
- 8 metal gobos plus full circle
- 1 Multicolor dichroic gobo, 2 dichroic gobos
Rotating gobos
- 1 metal gobo, 4 glass gobos and 1 dichroic gobo rotating in both dirrections at different speeds
- gobo indexing
- rotating gobo wheel cont. rotation
Strobe
- Strobe effect with variable speed (1 - 10 flashes per second)
Dimmer
Smooth dimmer from 0 - 100%
Effects
- Special effect wheel with frost filter, color temperature filters 3200 K and 5600 K, UV filter
Prisma
- 3 facet prism rotating in both dirrections at different speeds situated on effect wheel
Iris
Motorized iris for different beam diameters
Focus
Motorized focus from near to far
Motor
- 12 high quality stepper motors controlled by microprocessors
Electronics
- Digital serial input DMX-512
- 16 control-channels (full 16 bit protocol):
Channel 1: Horizontal mirror-movement 8 bit
Channel 2: Vertical mirror-movement 8 bit
Channel 3: Fine Horizontal mirror-movement 16 bit
Channel 4: Fine Vertical mirror-movement 16 bit
Channel 5: Pan/Tilt speed
Channel 6: Fan speed, On/Off lamp, reset
Channel 7: Colours

9. Technical Specifications
