D-Link DWP-1010/KT Schnelle Installationsanleitung Seite 10

TROUBLESHOOTING
RESETTING TO FACTORY SETTINGS
DWP-1010 (ODU)
Without access to the administration panel:
1. Hold the RESET button for 10 seconds - after a while the diodes will go out and the
factory settings will be restored.
2. After approx. 1 minute you can log in to the administration panel (default
192.168.100.1) using the default password.
Through the administration panel:
1. Click on the Administration > Manager tabs in the left panel, then "Reboot and
Reset" and "Reset" button.
2. The device will restart and restore the factory settings.
3. After approx. 1 minute you can log in again (default 192.168.100.1) using the default
password.
FIRMWARE UPGRADE OF DWP-1010
During the entire update process, do not pull out the Ethernet cable
and remain on the device page. The update process may take several
minutes!!!
To verify and update the software on the outdoor unit, follow these steps:
1. Connect your computer to the LAN input on the PoE Injector.
2. On your computer, open a web browser and enter 192.168.100.1 in the address bar.
3. Log in to the device using the default username and password. You can find this
information on the label located on the back of the DWP-1010 outdoor unit (Device
Password field).
4. Go to the Administration > Manager tab and select the FW Upgrade option.
5. If your unit has an active Internet connection, the latest available version will be
displayed in the New Firmware Version field.
6. To update, press the Upgrade button.
7. If your unit does not have an active Internet connection, go to the Firmware
Upgrade section.
8. In the FW Path field, press the Browse button and select the file with the software
the version you want to upload to the device, and then press the Upgrade button.
10
DWP-1010/K T
