LaserLiner MultiMeter-PocketBox Bedienungsanleitung Seite 11

4
2
3
E F G
C
B
D
Rotary switch to set the
1
measuring function
Switch over measuring
2
function
LCD
3
Holder for test prods
4
Hold actual measured
5
value
Measuring contacts:
6
black „–", red „+"
Test prods
7
Insertion of batteries / Replacing the fuse
1
MultiMeter-PocketBox
5
H I
A J
1
A Measured value display
(3.5 segments, 1999 digits)
Negative measured values
B
Direct (DC)
C
D Alternating (AC) variables
Automatic range selection
E
Diode test
F
G Continuity test
H Actual measurement is
retained
Low battery charge
I
Measurement units:
J
mV, V, mA, Ohm,
kOhm, MOhm
Display: O.L: Open line/
overflow: measuring
circuit not closed or
measuring range
exceeded
Isolate the device from all
current sources before opening
the battery compartment cover.
Do not switch on the device
with the cover open.
6
7
black red
