4. TECHNICAL DATA
Model
Power Supply Voltage
Power
Blade speed
Capacity
Dimensions
Poziom hałasu
The stated capacity is the theoretical capacity of the device. The exact capacity depends on the type of meat and
sieve.
5. ASSEMBLY
5.1.  Position
The place of installation of the device should be well lit and provide access to a source of power supply. The working
surface should be leveled, dry and sufficiently large. The installation should be conducted in accordance with the ap-
plicable legal regulations. Keep away from sources of heat (oven, cooker, etc.) and away from sources of water that
create a risk of flooding of the device.
5.2.  Connection to the power supply source
Caution: The device's connection to the electrical power source may only be executed by qualified employees of the
technical service. Make sure that the device is properly connected to the ground line. Before connecting the device,
make sure that the voltage and frequency at the location where the device will be used, are consistent with the values
indicated on the name plate. The device is equipped with a power cord. Use the above mentioned cord to connect the
device to an electrical outlet with a residual-current circuit breaker installed on the wall.
6. OPERATION
6.1.  Notes
Before disassembly and assembly the device must be turned off and disconnected from the power source. When
moving the device, carry it with both hands, holding by the motor housing. Do not carry the device holding by the tray.
Special caution should be exercised when moving the device because it is very heavy.
Never push products intended for grinding into the feed opening using your hands. Always use the pusher for this.
Do not grind hard products such as bones or nuts.
Do not use the device to grind products with hard fibers such as ginger. In order to avoid the clogging of products in
the grinding chamber, do not push them into the chamber with excessive force.
If the device jams because of hard products, which are stuck in the auger screw or on the knife, it is necessary to
immediately switch off and clean the device. (See point 5.5)
Don not attempt to disassemble the device or make repairs on your own. In the event of damage to the power cord, it
should be replaced by the supplier or his authorized service.
6.2.  Control panel
5
6
1
721129V02
230 V
0.55 kW
120 rev/min
up to 85 kg/h
410x190x350 mm
mniej niż 70 dB
2
3
4
1. Switch
2. REVERSE position - reverse gear
3. OFF position - turning off the operation of the device
4. Switch on device operation
5. Switch on the device after loss of power supply from
the mains or an emergency stop
6. Button for emergency stopping of device operation
- 11 -
