2.1.2. Steamer Cover

Follow the instructions in attaching or detaching the Steamer Cover given in figure 2.

2.1.3. Scent Basin

There is a designated hole for the Scent Basin on the Steamer Cover. The Scent Basin is to be
fitted on the hole as per Figure 3.
The Scent Basin should be handled with care as it might break if dropped on the floor or on any
hard surface.
Abb. 3 Duftbecken
Fig. 3 Scent Basin
2.2.

Installation

2.2.1. Mounting the Combi Heater

It is recommended that the Combi Heater is mounted on the wall nearest to the door.
A mounting rack is provided for attachment of the heater.
For safety and convenience, follow the minimum safety distances as provided in Figure 4.
Do not install the heater on a niche in the wall or let it stand on the floor.
Do not install more than one heater, unless, you follow the special instructions for twin-heater
installations.
Make sure to build a strong foundation for the mounting rack (e.g. cross struts in the
sauna paneling), or reinforce the wall with a thick board to prevent the heater from
collapsing. Refer to Figure 4 (Minimum Safety Distances/Wall Mounting Rack Installation
Guide) on how to attach the mounting rack to the wall.
Secure the mounting rack to the wall with the screws that are provided.
To mount the heater to the rack, fit the nuts on its back to the slots provided on both sides of the
mounting rack.
Make sure to lock the side screws to prevent the heater from being accidentally moved.
Duftbecken
Scent Basin
11
