3.3 How the cooktop extractor works
Depending on the model you purchased, the cooktop
extractor can be operated as an exhaust air or a
recirculating air version.
Exhaust air mode
The air suctioned away is purified by the grease filter
and expelled into the open air via a duct system. The
exhaust air must not be expelled into:
a smoke or exhaust gas flue that is in operation
a shaft used for the aeration of rooms where
fireplaces are installed.
If the exhaust air is to be directed into a smoke or
exhaust gas flue that is not in use, the installation must
be checked and approved by the responsible heating
engineer.
Recirculation mode
The air suctioned away is purified by the grease filter
and an activated charcoal filter and fed back into the
room in which the appliance is installed. To prevent
odours in recirculation mode, an odour filter must be
used. For hygiene and health reasons, the activated
charcoal filter must be replaced at the recommended
intervals (see the Cleaning and maintenance chapter).
3.4 How the induction cooktop works
3.4.1 Operating the hob with the sensor keys
The glass ceramic hob is operated with touch control
sensor keys. The sensor keys are operated as follows:
lightly touch a symbol on the surface of the ceramic
glass plate. A buzzer will indicate when the controls
have been operated correctly.
The touch control sensor key will then be indicated as
"key".
ON / OFF key (hob) (6)
This key is used to switch the entire hob on and off.
Cooking zone power setting display (8-9-10-12)
The power-setting indicator shows the power setting
which has been selected, or:
8
Appliance description
Fan power setting display (11)
The power setting display shows the power setting for
the fan which has been selected, or:
Lock key
The lock key can be used to lock all of the keys.
Keep warm key
To keep warm.
Power boost in the sensor field
The power boost setting makes additional power
available for induction cooking zones.
Pause key
The Pause function can be used to briefly stop the
cooking process.
Recall function
The most recent setting can be recovered if the hob is
switched off unintentionally.
Grill key
Grill function with a griddle plate for induction.
...................Residual heat
...................Power boost
...................Pan recognition
...................Heat up automatic
...................Pause function
....................Childproof lock
...................Bridging function
...................Keep warm level
...................Grill function
...................Error message
.............Automatic fan
..............Filter state indication
..............Error message
(14)
(15)
(13)
(13) (recovery function)
(16)
