AKIMIX Wood Stove
2 - USING WOOD GRANULES
• Set the air flow regulator to the
Important = the output regulator must
be open at maximum all the way to the to the
• Check that there are no obstructions below the granule distributor which might
hinder granules dropping into the crucible.
• Remove ash from the crucible to ensure adequate airflow for combustion and
ensure that it is properly positioned in its holder.
• Remove any ash from beneath the crucible using a poker, empty the ash pan as
necessary:
The area in the ash pan directly beneath the crucible must be
clear of obstructions.
• Ensure that the hearth door is closed properly.
• Close the hopper cover
• Read and apply the instructions in this manual.
SP, le 15/05/2018
Français – English - Deutsch
Reference 6190 34
granules
(page 11):
"
"
right hand end-stop.
Granule hopper
Page 33 sur 60
AKIMIX Wood Stove
To use granules for
heating
1- Turn the dial clockwise
and switch to granules
2 - Set the post-
combustion air regulator to
closed
3 - Set the output regulator to
"granules"
•
"
"
First use: Set the rear power switch to
ON
•
Lighting when using granules:
"
"
Set the airflow regulators to
Granules
(see diagram page 11)
o
o
Place some crumpled paper (avoid glossy paper) or
minimum. Light the fire and close the hearth door.
the appliance should remain under supervision.
After several minutes, check that the granules are alight.
o
o
Choose the output level required using the dial = see below
Lighting is "manual" and thus requires attention.
It is important to check whether flames are present once lit: if there no flames, and the wood starts to smoke, the
stove should be stopped.
Keep an eye on the stove for around 30 minutes until certain that it is operating correctly with an automatic supply of
granules.
•
"
"
Setting the type of granules: Set the dial to the
ON
dial is fully open, power output is 6kW.
Sleep mode
SP, le 15/05/2018
Français – English - Deutsch
Reference 6190 34
First use:
4 - Turn the secondary
airflow regulator to closed
"
"
fire-lighters
on the grid and a handful of granules, turn the dial clockwise to
It may be useful to leave the hearth door open slightly while lighting, but
position. To increase output, turn the dial clockwise (see diagram below). When the
•
Green ON = granule feed is operational
OFF = stove is off
•
Red ON = granule feeder is working
OFF = granule feeder screw is blocked
Power:
Autonomy:
3.5 kW
17 h
6.5 kW
8 h
Page 34 sur 60
