AKIMIX Wood Stove
INSTALLATION INSTRUCTIONS
To ensure that surrounding surfaces do not exceed 65 °C above room temperature, surrounding objects must be positioned at distances
in accordance with the table below.
If the surrounding walls are not made of flammable material or be degraded by heat (the temperature of the wall may reach 200 °C),
distances can be reduced by half to 400 mm.
This distance is required to access the rear of the appliance, to the "use granules" switch and for maintenance and cleaning of the
granules feed system.
FLOOR PLAN OF STOVE INSTALLATION
800 mm
800 mm
Floor protection plate
SP, le 15/05/2018 Français – English - Deutsch
Reference 6190 34
Rear
wall
Page 25 sur 60
AKIMIX Wood Stove
Expanded:
SP, le 15/05/2018 Français – English - Deutsch
Reference 6190 34
Page 26 sur 60
