AKIMIX Wood Stove
Whichever method is used (normal output or long period), ensure that the initial load of wood is properly lit and that the flame is
If not, move the output regulator to the
maintained.
catch.
Ensure that flames are present during combustion of the volatile fraction of the wood, to avoid the stove or flue sooting-up and
emissions which might be harmful to health or the environment.
Post combustion activated = GOOD
Stove hot and clean
" "
Glass is clean
Air post-
combustion
Clean
air
•
Regulator settings:
Output Regulator: Is used to switch the appliance from
The output regulator may be used when using either logs or granules. Instructions for use with granules are detailed below.
USING WITH WOOD GRANULES»
Lighting position: When using LOGS, setting the output regulator above "normal output" increases airflow for lighting.
The regulator should not be left in this position for more than 30 minutes, doing so may damage the appliance and its environment. The
appliance should remain under supervision during lighting.
Secondary air regulator:
The secondary air regulator should remain open at all times to achieve complete burning. This setting needs
to be adjusted only with higher than recommended airflows (see above) This setting can be changed in this case to obtain a satisfactory
output. Once adjusted, do not change the secondary airflow setting to modify the output of the appliance. Use the output regulator to
increase or decrease output.
Post-combustion setting
The secondary air regulator should remain open at all times to achieve complete burning.
The regulators may be very hot. Always use the heat resistant glove supplied with the appliance when touching the regulators.
SP, le 15/05/2018 Français – English - Deutsch
Reference 6190 34
lighting position to increase airflow and allow the wood to
" "
Combustion without flames = BAD
Stove cold and dirty
" "
Glass is
Bed of
embers
" normal output " to " usage for long periods "
Page 31 sur 60
OUTPUT AND SECONDARY AIR REGULATORS
-
The output regulator, situated on the front of the appliance, is used to vary output when changing over from one fuel type to
another:
Secondary air regulator:
Normal output for wood
Turn the regulator to the
left for usage over a long
period.
POST-COMBUSTION REGULATOR
« 2 –
Open Closed
Open Closed
Normal output for
Turn the regulator to the
left for usage over a long
period.
Post-combustion air
flow regulator
Using logs:
•
Output regulator to
•
Secondary air regulator
•
Post combustion regulator
SP, le 15/05/2018 Français – English - Deutsch
AKIMIX Wood Stove
Lighting + granules position
Using granules:
•
normal wood Output regulator set to
" "
(open to maximum, all the way to the right end-
open
" "
stop)
open
" "
•
Secondary air regulator
•
Post-combustion regulator
Reference 6190 34
granules
" "
" closed "
closed
" "
Page 32 sur 60
