811 STEUERWORT KONFIGURATION bit 00
811
(CW CONFIG 00)
Wert:
Preset ref lsb (PRESET REF LSB)
Preset ref msb (PRESET REF MSB)
DC Braking (DC BRAKING)
Coasting stop (COASTING STOP)
Quick stop (QUICK STOP)
Freeze out freq (FREEZE OUT FREQ)
✭Ramp stop start (RAMP STOP START)
Reset (RESET)
Jog (JOG)
Ramp 1 or ramp 2 (RAMP 1 OR RAMP 2)
Data valid (DATA VALID)
Relay 1-3 (RELA Y 1-3)
No function (NO FUNCTION)
Select set up lsb (SELECT SET UP LSB)
Select set up msb (SELECT SET UP MSB)
Reversing (REVERSING)
No function (NO FUNCTION)
Funktion:
Wählt eine Funktion aus den Bits des 16 Bit-
Steuerworts.
(16 = no operation)
812 STEUERWORT KONFIGURATION bit 01
812
(CW CONFIG 01)
Wert:
Preset ref lsb (PRESET REF LSB)
Preset ref msb (PRESET REF MSB)
DC Braking (DC BRAKING)
Coasting stop (COASTING STOP)
✭Quick stop (QUICK STOP)
Freeze out freq (FREEZE OUT FREQ)
Ramp stop start (RAMP STOP START)
Reset (RESET)
Jog (JOG)
Ramp 1 or ramp 2 (RAMP 1 OR RAMP 2)
Data valid (DATA VALID)
Relay 1-3 (RELA Y 1-3)
No function (NO FUNCTION)
Select set up lsb (SELECT SET UP LSB)
Select set up msb (SELECT SET UP MSB)
Reversing (REVERSING)
No function (NO FUNCTION)
Funktion:
Wählt eine Funktion aus den Bits des 16 Bit-
Steuerworts.
6
®
VLT
Serie FCD
(16 = no operation)
[0]
813 STEUERWORT KONFIGURATION bit 02
813
[1]
(CW CONFIG 02)
[2]
Wert:
[3]
✭Preset ref lsb (PRESET REF LSB)
[4]
Preset ref msb (PRESET REF MSB)
[5]
DC Braking (DC BRAKING)
[6]
Coasting stop (COASTING STOP)
[7]
Quick stop (QUICK STOP)
[8]
Freeze out freq (FREEZE OUT FREQ)
[9]
Ramp stop start (RAMP STOP START)
[10]
Reset (RESET)
[11]
Jog (JOG)
[12]
Ramp 1 or ramp 2 (RAMP 1 OR RAMP 2)
[13]
Data valid (DATA VALID)
[14]
Relay 1-3 (RELA Y 1-3)
[15]
No function (NO FUNCTION)
[16]
Select set up lsb (SELECT SET UP LSB)
Select set up msb (SELECT SET UP MSB)
Reversing (REVERSING)
No function (NO FUNCTION)
Funktion:
Wählt eine Funktion aus den Bits des 16 Bit-
Steuerworts.
(16 = no operation)
[0]
814 STEUERWORT KONFIGURATION bit 03
814
[1]
(CW CONFIG 03)
[2]
Wert:
[3]
Preset ref lsb (PRESET REF LSB)
[4]
✭Preset ref msb (PRESET REF MSB)
[5]
DC Braking (DC BRAKING)
[6]
Coasting stop (COASTING STOP)
[7]
Quick stop (QUICK STOP)
[8]
Freeze out freq (FREEZE OUT FREQ)
[9]
Ramp stop start (RAMP STOP START)
[10]
Reset (RESET)
[11]
Jog (JOG)
[12]
Ramp 1 or ramp 2 (RAMP 1 OR RAMP 2)
[13]
Data valid (DATA VALID)
[14]
Relay 1-3 (RELA Y 1-3)
[15]
No function (NO FUNCTION)
[16]
Select set up lsb (SELECT SET UP LSB)
Select set up msb (SELECT SET UP MSB)
Reversing (REVERSING)
No function (NO FUNCTION)
Funktion:
Wählt eine Funktion aus den Bits des 16 Bit-
Steuerworts.
