Bender AN450 Handbuch Seite 4

Versorgungsspannung
Nennspannung ........................................................... siehe Bestellangaben
Frequenzbereich ......................................................................... 50...60 Hz
Arbeitsbereich der Nennspannung ................................................0,85...1,1
Ausgangsspannung ........................................................ AC 20 V, 50...60 Hz
Ausgangs-Nennleistung ......................................................................≤ 9 VA
Sekundäre Sicherung .......................................................................Kaltleiter
Umwelt/EMC
EMV Störfestigkeit ...........................................................nach EN 61000-6-2
EMV Störaussendung .......................................................nach EN 61000-6-4
Arbeitstemperatur ............................................................... 10 °C...+ 55 °C
Klimaklassen nach IEC 60721
Ortsfester Einsatz ............................................................................3K22
Transport ........................................................................................2K11
Langzeitlagerung ............................................................................1K21
Mechanische Beanspruchung nach IEC 60721
Ortsfester Einsatz ............................................................................3M11
Transport .........................................................................................2M4
Langzeitlagerung ...........................................................................1M12
Anschluss
Anschlussart ....................................................................... Schraubklemmen
Anschlussvermögen:
starr/flexibel/Leitergrößen ...............0,2...4 / 0,2...2,5 mm2 / AWG 24-12
flexibel mit Aderendhülse ....................................................... 0,25...2 mm2
Abisolierlänge .......................................................................................8 mm
Anzugsmoment ..................................................................................0,5 Nm
Allgemeine Daten
Betriebsart ................................................................................ Dauerbetrieb
Einbaulage ........................................................................................ beliebig
Schutzart Einbauten/Klemmen (DIN EN 60529) ..............................IP30/IP20
Schraubbefestigung .............................................................................2 x M4
Schnellbefestigung auf Hutprofilschiene ................ DIN EN 60715/IEC 60715
Entflammbarkeitsklasse ................................................................... UL94V-0
Produktnormen ..................................................................DIN EN 61558-2-6
Gewicht ............................................................................................. ≤ 400 g
Bender GmbH & Co. KG
Londorfer Straße 65
35305 Grünberg
Germany
Tel.: +49 6401 807-0
info@bender.de
www.bender.de
Voltage ranges
Rated voltage ...................................................................see ordering details
Frequency range ........................................................................... 50...60 Hz
Operating range of rated voltage ...................................................0.85...1.1
Output voltage ............................................................... AC 20 V, 50...60 Hz
Rated output Power .............................................................................≤ 9 VA
Internal secondary protection ..................................................... PTC resistor
Enviroment/EMC
EMC immunity .............................................................. acc. to EN 61000-6-2
EMC emission ................................................................ acc. to EN 61000-6-4
Operating temperature ...................................................... - 10 °C...+ 55 °C
Classification of climatic conditions acc. to IEC 60721
Classification of mechanical conditions acc. to IEC 60721
Connection
Connection .............................................................................screw terminals
Connection properties:
rigid/flexible/Conductor sizes ...........0.2...4 / 0.2...2.5 mm2 / AWG 24-12
Connection, flexible with connector sleeve ............................. 0.25...2 mm2
Stripping length ....................................................................................8 mm
Tightening torque, terminal screws ....................................................0.5 Nm
General data
Operating mode ........................................................... continuous operation
Mounting .....................................................................................any position
Protection class internal components/terminals (DIN EN 60529) ....IP30/IP20
Screw fixing .........................................................................................2 x M4
DIN rail mounting acc. to ......................................... DIN EN 60715/IEC 60715
Flammability class ............................................................................ UL94V-0
Standards .................................................................................IEC 61558-2-6
Weight ............................................................................................... ≤ 400 g
Alle Rechte vorbehalten.
Nachdruck und Vervielfältigung nur mit
Genehmigung des Herausgebers.
All rights reserved.
Reprinting and duplicating only with
permission of the publisher.
Stationary use ..................................................................................3K22
Transport ......................................................................................... 2K11
Storage ............................................................................................ 1K21
Stationary use .................................................................................3M11
Transport ..........................................................................................2M4
Storage ..........................................................................................1M12
© Bender GmbH & Co. KG, Germany
Subject to change! The specified
standards take into account the edition
valid until 03/2024 unless otherwise
indicated.
