Technical information

1. Misting Board
2. Front Grill
3. Misting Board Lock Screws
4. Blade Lock Nut
5. Blades
6. Grill Lock Nut
7. Back Grill
8. Motor Shaft
9. Motor Cover
10.Grill Ring
11. Grill Lock Nut
12. Motor Holder
13. Connection Holder
14. Main Holder
15. Power Connection Line
16. Holder Fixed Screw
17. Main Body
18. Water Tank
19. Water Outlet Lock nut
20. Base
21. Wheels
22. Base Lock Nut
23. Misting Tube
24. Control Panel
25. Remote Control
26. Decorate Panel
27. Water Indicator
