MECHANICAL AND ACOUSTIC FEATURES
DIMENSIONS AND WEIGHT
The IS series has been designed with particular attention to optimising the overall dimensions. The weight is just
2 kg for the IS4T, 2.8 kg for the IS5T and 4 kg for the IS6T.
The main dimensions are:
130 x 130 x 150mm (WxHxD) - IS4T model
160 x 160 x 180mm (WxHxD) - IS5T model
195 x 195 x 210mm (WxHxD) - IS6T model
IS4T
IS5T
IS6T
IS4T-IS5T-IS6T
14
W
195
201
Ws
D
W H
130 mm 130 mm
160 mm 160 mm
195 mm 195 mm
D Ws
150 mm 136 mm 170 mm
180 mm 166 mm 205 mm
210 mm 201 mm 245 mm
English
H
Hs
Ds
120
Hs Ds
100 mm
110 mm
120 mm
Cod. 420120373 REV. 1.3
