Operation instructions | IPQAM (EdgeQAM) | IP zu DVB-T2
Type
IPTV input
Max. number (out of SPTS or MPTS)
Total net data rate
Transportstreams
Modifiable program information
PCR correction
LCN
EPG regeneration
Encryption
Output
Number of channels
Frequency range
Channels selectable
Channel bandwidth
Possible frequency shift
Connector
Test port
Impedance
Output level adjustable
Output modulation
Compliance
L1 post signalling
Type
Supported output formats
MER
BER
Shoulder attenuation
C/N
Reflection
Bit rate, max
FFT
FEC type
FEC length
FEC
Page 74 of 80
MIE 108-02N
512
1 × 900 Mbps
Program name, SID remapping, PID filtering, TSID, ONID
DVB-CSA* | DVB-CISSA* | ATIS-IDSA* | AES-ECB* | AES-CBC*
1 × 10 × DVB-T2
85 ... 105 dBµV
EN 50083-9 | ETSI TS 101 154 | ETSI EN 300 429 | ETSI EN 300 744
MPEG-2/H.262, MPEG-4/H.264 and HEVC/H.265
BA_MIE-N.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2024-01-19
MIE 208-02N
2 × 512
2 × 900 Mbps
automatic, adaptive, < 500 ns
Yes
Yes
2 × 10 × DVB-T2
114 ... 1006 MHz
D114 ... D1002
7/8 MHz
−4 ... +4 MHz (0.5 MHz steps)
1 × F-female
1 × F-female (–30 dB)
75 Ω
87 ... 105 dBµV
DVB-T2 (EN 302 755, mode A (single PLP))
BPSK, QPSK, 16-QAM, 64-QAM
QPSK, 16-QAM, 64-QAM, 256-QAM
> 43 dB
< 9 x 10-9
> 56 dB
> 45 dB
< −14 dB
49.9 Mbps
1k, 2k, 4k, 8k mode (ext)
BCH, LDPC
16200, 64800
1/2, 3/5, 2/3, 3/4, 4/5, 5/6
MIM 108-02N
512
1 × 900 Mbps
1 × 10 × DVB-T2
86 ... 105 dBµV
