axing IPQAM MIE 24-00N Betriebsanleitung Seite 150

Operation instructions | IPQAM (EdgeQAM) | IP zu DVB-T2
Type
IPTV input
Supported input transport streams
Max. number (out of SPTS or MPTS)
Supported protocols
Total net data rate
Transportstreams
Modifiable program information
PCR correction
LCN
EPG regeneration
Encryption
Output
Number of channels
Frequency range
Channels selectable
Channel bandwidth
Possible frequency shift
Connector
Test port
Impedance
Output level adjustable
Output modulation
Compliance
L1 post signalling
Type
Supported output formats
MER
BER
Shoulder attenuation
C/N
Reflection
Bit rate, max
FFT
FEC type
FEC length
Page 70 of 80
MIE 4-02N
512
1 × 900 Mbps
Program name, SID remapping, PID filtering, TSID, ONID
DVB-CSA* | DVB-CISSA* | ATIS-IDSA* | AES-ECB* | AES-CBC*
1 × 4 × DVB-T2
1 × F-female
1 × F-female (–30 dB)
EN 50083-9 | ETSI TS 101 154 | ETSI EN300 429 | ETSI EN 300 744
MPEG-2/H.262, MPEG-4/H.264 and HEVC/H.265
BA_MIE-N.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2024-01-19
MIE 8-02N
SPTS, MPTS (CBR/VBR)
2 × 512
IP V4; UDP; RTP; IGMP v2, v3
2 × 900 Mbps
automatic, adaptive, <500 ns
Yes
Yes
2 × 4 × DVB-T2
-
S2...K69
-
-4...+4 MHz (0.5 MHz steps)
2 × F-female
2 × F-female (–30 dB)
75 Ω
85...105 dBµV
DVB-T2 (EN 302 755, mode A (single PLP))
BPSK, QPSK, 16QAM, 64QAM
QPSK, QAM16, QAM64, QAM256
≥ 43 dB
≥9x10-9
≥ 56 dB
≥45 dB
>14 dB
47.7 Mbps
1K, 2K, 4K mode
BCH, LDPC
16200, 64800
MIM 4-02N
512
1 × 900 Mbps
1 × 4 × DVB-T2
1 × F-female
1 × F-female (–30 dB)
