LEAKSHIELD
Virtual software sensors are updated once per second and re-calculated with the
numbers valid in that particular moment. When using fast changing input values,
extreme values can therefore either be used or ignored for the calculation. No
smoothing or averaging is taking place.
19.3. Output actions
19.3.
Output actions
19.3.
19.3.
Output actions
Output actions
While the virtual software sensors are used as a value within the aquasui-
te, output actions configured in this section are used to trigger events. Va-
rious notification events including emails and MQTT messages are
available. Additionally, external programs can be started.
Create a new output action by clicking the plus symbol in the upper right corner of
the "Output actions" window and configure the properties as desired. Each output
action always has an "Output" element which represents the event itself. In the set-
tings dialog of this element, the event to be executed can be selected and configu-
red.
You can now add data sources and function blocks to the lower area of the win-
dow and connect inputs and outputs of the blocks with lines. Connect the output
of the last function block with the "Output" element. The event will be executed
when the input of the "Output" element reaches a value greater than zero.
Output actions are updated once per second and re-calculated with the numbers
valid in that particular moment. When using fast changing input values, extreme
values can therefore either be used or ignored for the calculation. No smoothing
or averaging is taking place. Example: If thresholds are exceeded for very short
periods of time lasting less than one second, the action can be executed or not be
executed seemingly at random, depending on whether the thresholds is exceeded
in the exact moment the calculation is performed.
19.4.
19.4.
19.4. Global profiles
19.4.
Global profiles
Global profiles
Global profiles
The global profile management can be used to conveniently change set-
tings in multiple devices simultaneously and activate desktop pages. Indi-
vidual actions can be defined for each of the four profiles, switching bet-
ween profiles can either be done manually or automatically depending on confi-
gurable rules.
In order to use this feature, set up profiles within the individual device configurati-
ons first. These profiles can then be activated using the global profile manage-
ment. Not every type of device supports profiles.
