LEAKSHIELD
Gauge: Displays the value as a analog gauge.
●
All display styles offer extensive configuration options, additionally statistical data
such as minimum, maximum and average can be displayed.
9.7.
9.7. Log data chart
Log data chart
9.7.
9.7.
Log data chart
Log data chart
This element can be used to display charts on overview pages. The charts have to
be created using the data log functionality of the aquasuite before they become
available for overview pages. Please refer to the next chapter for details. Once a
chart has been configured, it can be selected from the "Chart selection" list on the
"Display" tab of the settings dialog.
9.8.
9.8.
9.8. User defined: Images, text, drawing elements
9.8.
User defined: Images, text, drawing elements
User defined: Images, text, drawing elements
User defined: Images, text, drawing elements
By using user defined controls, simple drawing elements such as circles, rectangles
and texts as well as images and more sophisticated elements can be added to an
overview page. To do so, add an "User defined" element to an overview page.
Switch to the "Display" tab in following dialog box, select the type of element to be
created from the drop down menu and confirm your selection by clicking the
"Load preset" button. Depending on the type of element, an additional dialog may
appear before the code (XAML, Extensible Application Markup Language) of the
new element is displayed in the lower part of the dialog window. You may want to
customize the code. By clocking the "Ok" Button, the new control is saved to the
overview page.
Step-by-step example to add an image: Select "Image" from the drop down menu
and click the "Load preset" button. Select an image file using the following file se-
lection dialog. The code is then displayed in the lower part of the dialog window
an can be modified. Save the new control by clicking the "Ok" button. The picture
will be displayed on the overview page.
More complex controls such as data bindings and animations are also available
but will require some programming experience for configuration.
9.9. Export and import of overview pages
9.9.
9.9.
9.9.
Export and import of overview pages
Export and import of overview pages
Export and import of overview pages
Elements and complete overview pages can exported from the aquasuite and can
then be imported either on the same PC or on other PCs. For export as well as im-
port, the overview page must be in edit mode.
To export a complete page, right click a free spot of the page and select "Export
page" from the context menu. To export individual elements, select the element or
elements, perform a right click and select "Export selected" from the context menu.
For import, right click a free spot of the page and select "Import page" or "Import
items"from the context menu. Using "Import page", the current page will be dele-
ted and only the imported page items will be displayed, using "Import items" will
add the items from file to the current page without altering the existing items. Du-
ring import, the elements will be assigned to devices using the following scheme:
- 12 -
