18.5. Firmware update and language selection (aquasuite only)
18.5.
18.5.
18.5.
Firmware update and language selection (aquasuite only)
Firmware update and language selection (aquasuite only)
Firmware update and language selection (aquasuite only)
The most up to date firmware for all supported devices is always included in the
current version of the aquasuite software. The button " Update firmware now" will
start the update process for the device firmware.
During the firmware update process, do not disconnect the device from the PC
and do not power down the PC! After the firmware is successfully updated, the
aquasuite software will be automatically closed.
19. Playground (aquasuite)
19.
Playground (aquasuite)
19.
19.
Playground (aquasuite)
Playground (aquasuite)
Click the entry "Playground" to configure Virtual Software Sensors, global profile
management and hotkeys.
19.1. Input values
19.1.
Input values
19.1.
19.1.
Input values
Input values
Input values defined in this section can be manipulated by individually
configured control elements, for example sliders or buttons.
Create a new input value by clicking the plus symbol in the upper right corner of
the "Input values" window and configure the properties as desired. A name, an
icon, a unit, a range of values as well as a initial value can be assigned to each
input value. This new input value will then be available to be displayed on over-
view pages and in the quick view section and can be used as a data source for
software sensors and virtual software sensors.
In the lower area of the window, control elements can be created and configured
to manipulate the input value. These preconfigured control elements can then be
used for overview pages or in the system tray.
19.2. Virtual Software Sensors
19.2.
Virtual Software Sensors
19.2.
19.2.
Virtual Software Sensors
Virtual Software Sensors
Virtual Software Sensors can be used for extensive yet easy to use adapta-
tion and calculation of sensor values using mathematical and logical
functions as well as filters.
Create a new Virtual Software Sensor by clicking the plus symbol in the upper right
corner of the "Virtual Software Sensors" window. Each Virtual Software Sensor al-
ways has an "Out" element which will provide the resulting sensor value. In the
settings dialog of this element, the name and unit of the sensor can be configured.
You can now add data sources and function blocks to the lower area of the sensor
window and connect inputs and outputs of the blocks with lines. Connect the out-
put of the last function block with the "Out" element.
The resulting virtual sensor can be used within the aquasuite software, for example
for overview pages, additionally it may be transmitted via USB connection to
connected devices that feature software sensors.
The following (very simple) example calculates the average out of two temperatu-
res:
© 2021-2024
Aqua Computer GmbH & Co. KG
Gelliehäuser Str. 1, 37130 Gleichen
LEAKSHIELD
- 29 -
